3DS MAX -PRO BOOLEAN TUTORIAL

hiiiii friends,

Reverse pro boolean process

Difference between boolean and pro boolean is pro boolean is offering multiple subtract.

Object and only boolean tool subtract only one object when you  try to select second object for subtracting first object appear automatic. so, Pro boolean tools is more effective.

Today we learn how can subtract an object in 3d studio max.

 An engineer or a designer usually put pergola design , wall subtracted design in parapet and compound wall etc. This time we require this tool.Called proboolean.

First, i create simply a scene

Now i want to get some pergola type design because my roof is like a plane box.

I have to create first object which i will subtract.

I select my roof object and go to drop-down list from control panel-standard primitives and select compound object.

(image shown bellow)

.

From compound object menu i select pro boolean (must be select object)...here you find same two type tool only boolean and proboolean. well we will get know the difference between above two tools later...

After the select pro boolean tool in pick boolean tab select start picking the object one by one which will i want to subtract from roof object.

Finally i create pergola design from using pro boolean tool.

I also change this operation reverse by select object from view port next select object in parameter list which is already subtracted and click on extract selected.

after render the scene.

You can also use this tool in elevation design , parapet design and different type of uses.

Keep learning......and make it easy.
